Back to topFunction characteristics:
Low the highest resolution can reach 3 million
2560 * 1536 pixels), the frame rate of 30 FPS
When using advanced video compression technology
High compression ratio and processing is very flexible
Progressive-scan CMOS low capture images without sawtooth
Double filter automatic switching, three lattice infrared distance 40 meters
Low double stream motion detecting password protection
Low flicker heartbeat watermark technology, CVBS video output
Low compatible Onvif GB/T28181 standard
Enlarge imageBack to topApplication scenarios:
Apply to the financial, telecommunications, supermarkets, hotels, government, schools, factories, public security, justice, peace city high clear image quality, and so on performance is required.
Back to top|
model |
SR-NC7513L |
|
imager |
1/3' 1.3MP CMOS |
|
Minimum illumination |
0.1 Lux |
|
lens |
3.6mm/6mm |
|
Day and night conversion mode |
The double filter switch day and night |
|
video management software |
256 road access at the same time |
|
Video compression standard |
H.264/Mjpeg |
|
Compressed output bit rate |
16K-6Mbps |
|
Audio compression standard |
G.711/G.726 |
|
Maximum image size |
1280*960 |
|
Frame rate |
1-30 |
|
Image set |
Brightness, contrast, saturation, sharpness, etc by the client or Internet explorer is adjustable |
|
Intelligent alarm |
The motion detecting, external alarm input |
|
Support agreement |
TCP/IP,HTTP,DHCP,DNS,DDNS,RTP,RTSP, PPPoE,SMTP,NTP,UPnP,FTP,802.1x, |
|
Common functions |
A key recovery, double stream, password protection, video covering |
|
Communication interface |
A RJ45 10 m / 100 m adaptive Ethernet front-end ports |
|
Working temperature and humidity |
temperature： 0℃-45℃(32-113°F) humidity： 20-80%RH |
|
power supply |
DC12V±10% |
|
Power consumption |
4.5W MAX |
|
weight |
310g |
Back to top
