Model

SR-NH6220-20

 Imaging source

1/2.8" SONY CMOS

 Signal model

PAL/NTSC

 Clarity

1080P

 Effective pixels

1920 (horizontal) x 1080 (vertical)

 Minimum illumination

Color black and white, color: 0.01 Lux 0.001 Lux black and white

 Signal to noise ratio

>60dB（strengthen）

 Backlight compensation

On/off

 White balance

automatic

 Electronic shutter

PAL:1/25~1/100000s  NTSC:1/30~1/100000s

 Focal length

4.7~94mm

 Optical zoom

20 times

 Focusing

Automatic/manual/automatic keying, digital high-speed continuous af function is realized by using high performance DSP

 Presetting bit

256

 Synchronized scanning

Article 4, each can record 200

 Cruise trajectory

Preset 30 points can take part in the cruise, preset point residence time can be set up

 Other scanning

Support level, two areas, random scanning scan

 Rotation range

Level 360 ° unlimited, 90 ° vertically, automatic reverse it

 Rotation speed

The horizontal and vertical: minimum 0.01 degrees, the maximum 200 degrees per second

 Video coding

H.264 Main Profile code；MJPEG/JPEG Baseline code

 Audio coding

G.711，G.726，Support 32 K stereo

 Image is the main stream

1920*1080,25 frames per second

 The image time stream

 640*480，25 frames per second

 Video compression bit rate

32Kbps-16Mbps continuous adjustable ,support CBR/VBR

 Protocol support

TCP/IP、UDP、RTP、RTSP、RTCP、HTTP、DNS、DDNS、DHCP、FTP、NTP、PPPOE、SMTP、UPNP

 ONVIF protocol

support

 Power supply

DC12V/3A

 The ball machine material

Metal aluminum shell

 Work environment

-20℃～+50℃（Equipped with temperature control components），＜95%RH
