Back to topThe main function characteristics:
Low real-time output full 720 P (720 P / 720 P / 50 model)
Low metal shell, thermal infrared lamp and separated structure
Kop ir 150 meters, power off memory function
Continuous rotation, low level of 360 ° 180 ° vertical automatic reverse it
18 x optical zoom, double filter, day and night switch (ICR)
Low digital wide dynamic, digital noise reduction, privacy masking, prevent flashing function
When an LVDS (ITU - R BT1120) output video format
Low UC client control
Second-ranking supports a variety of network protocols: HTTP, TCP/IP, UDP, SMTP, DDNS, PPPOE, FTPNTP, UPNP, etc
Enlarge imageBack to topApplication scenarios:
Can be widely applied to the needs of a wide range of high speed monitoring sites, such as rivers, forests, roads, railways, airports, ports, sentry, square, park, scenic spot, the streets, railway stations, large venues, peripheral etc.
Back to top|
Model |
SR-NH7213D-20 |
|
Infrared distance |
150 - meter infrared distance |
|
Cruise scanning |
4 |
|
Horizontal velocity |
0.08°—300°/S |
|
Vertical speed |
0.08°—300°/S |
|
Horizontal rotation range |
Continuous rotate 360 ° |
|
Oblique rotation range |
+3°～-90° |
|
Focus speed control |
automatic |
|
Network interface |
10/100 m network adaptive, RJ45 adapter |
|
Video coding |
H.264 Main Profile coding |
|
The video compression bit rate |
256 KBPS - 12 MBPS continuous adjustable support CBR/VBR |
|
data storage |
Video and image files |
|
The client browse |
Support IE6.0 and above (device embedded Web Server) access |
|
Protocol support |
HTTP、TCP/IP、UDP、SMTP、DDNS、PPPOE、FTPNTP、UPNP |
|
Effective pixels |
1305（H）×1049（V） |
|
Signal to noise ratio |
≥50dB（Automatic gain clearance） |
|
Minimum illumination |
0Lux IR ON |
|
Image rollovers |
standard/Or so/Up and down/diagonal |
|
To switch between day and night |
Color, black and white, internal and external (LSR) |
|
Automatic gain |
Low, medium and high |
|
white balance |
ATW/USER1-5/ONEPUSH |
|
Wide dynamic |
On / off |
|
2 D digital noise reduction |
On/001-007/off |
|
Video format |
LVDS（ITU-R BT1120） |
|
focal length |
4.7mm-84.6mm（18 times） |
|
aperture |
F1.5～F3.5 |
|
Focus range |
30cm(1 times)～1000m |
|
Change of times |
About 5 seconds (wide Angle - distance) |
|
menu |
Chinese English |
|
Optional support |
Wall/lifting |
|
The IP rating |
IP66 |
|
service voltage |
DC12V（9V～18V） |
|
Working temperature |
-10℃～+50℃(14℉~122℉) |
|
Store humidity |
＜85%（No condensation） |
