Model

SR-SH6107D-27

Imaging source

1/3" Sony CCD

Signal model

PAL/NTSC

Clarity

700 line

Effective pixels

976 (horizontal) x 596 (vertical)

Minimum illumination

Infrared lamp open 0 lux

Signal to noise ratio

≥50dB（AGC OFF）

Backlight compensation

On/off

White balance

automatic

Electronic shutter

PAL:1/50~1/10000 seconds  NTSC:1/60~1/12000 seconds

Focal length

3.2~86.4mm

Optical zoom

27 times

Focusing

Automatic/manual/automatic variable times

Presetting bit

256

Synchronized scanning

Article 4, each can record 500

Cruise path

8 groups (each group of 32 preset digits)

Infrared projection distance

80-120M

Vertical scope

-10°-90°

Manual speed

0.01°-180°/seconds

Protocol

PELCO D  and  PELCO P

Menu features

Full screen in both Chinese and English menu

Synchronously

inter-sync/power synchronization

Infrared life

30000hours

The power supply

DC12V/4A

Protection grade

IP66

Work environment

-35℃～+65℃
