Back to top1、Use 10 times the Mini type high-definition color video camera;
2、Level 360 ° rotation, precision stepper motor drive, stable operation, precise position;
3、 Rotation speed adjusted automatically according to the lens change multiple times, automatic focusing, automatic white balance;
4、Built-in full-screen OSD menu screen. Compatible with a variety of control protocol, baud rate is adjustable;
5、90 ° vertically, automatically turn 180 ° after continuous monitoring.
Enlarge imageBack to top|
Model |
SR-SM4107D-10 |
|
Imaging source |
1/3" Sony CCD |
|
Signal model |
PAL/NTSC |
|
Clarity |
700 line |
|
Effective pixels |
976 (horizontal) x 596 (vertical) |
|
Minimum illumination |
Color black and white, color: 0.01 Lux, black and white: 0.001 Lux |
|
Signal to noise ratio |
>60dB（strengthen） |
|
Backlight compensation |
On/off |
|
White balance |
automatic |
|
Electronic shutter |
1/50~1/12000 seconds |
|
Focal length |
3.9~39mm |
|
Optical zoom |
10 times |
|
Focusing |
Automatic/manual, USES the high performance DSP to realize full digital high-speed continuous af function |
|
Presetting bit |
256 |
|
Synchronized scanning |
Article 4, each can record 200 |
|
Cruise trajectory |
Preset 30 points can take part in the cruise, preset point residence time can be set up |
|
Other scanning |
Support level, two areas, random scanning scan |
|
Rotation range |
Level 360 ° unlimited, 90 ° vertically, automatic reverse it |
|
Rotation speed |
The horizontal and vertical: minimum 0.01 degrees, the maximum 200 degrees per second |
|
Communication methods |
RS-485，PELCO D,PELCO P |
|
Menu features |
full screen menu |
|
Temperature control system |
Built-in temperature control system |
|
Power supply |
DC12V/2A |
|
Ball machine material |
Metal aluminum shell |
|
Work environment |
-20℃～+50℃（Equipped with temperature control components），＜95%RH |
